B610 Specification
| Sensor | 8MP,1/1.8" CMOS |
| Effective Pixels | 3840*2160 |
| Bit | 12bit |
| Pixel Size(μm) | 2.0μm*2.0μm |
| FPS | 60fps@1920*1080 |
| Scan mode | Progressive scan |
| Shutter Type | Electronic shutter |
| Dynamic Range | Linear Mode 75dB; Wide Dynamic Range Mode >100 dB |
| SNR | 39dB |
| Exposure Mode | Manual / Auto |
| White Balance | Manual / Auto |
| Lens Mount | C/CS |
| Interface | HDMI + USB2.0 |
| Image Capture | U-disk memory |
| Output Resolution | HDMI:1920*1080; USB2.0(UVC): 3840*2160 / 1920*1080 |
| USB function | U-disk |
| Remote Control | Yes |
| Power Supply | DC 12V/1A Adapter |
| Size | 58*58*48mm |
| Functions | 1. Digital magnification：support 2× magnification 2. Measurement ruler tool：Length, proportion, and color are adjustable; supports 3 concentric circles with adjustable radii and 2 adjustable rays ranging from 0–360°. 3. Cloning function: Allows exporting/importing settings for quick parameter setting replication. 4. Supports segmented video recording (5-30min.) 5. Upgrade: Supports upgrading via USB drive. |
Product Advantages
Structural and Modular Design Innovation
Designed with flexibility and efficiency in mind, the camera integrates HDMI and USB output interfaces into a compact architecture, allowing seamless adaptation to various inspection and imaging environments. Support for high-capacity USB flash drives (Max. 128GB) enables direct image and video storage without additional hardware. Built-in concentric circle and crosshair overlays provide practical visual references for sample positioning and alignment, while the Clone Function simplifies device deployment by allowing rapid duplication of camera settings across multiple units, ensuring consistent performance and reduced setup time.
Operational Excellence and User-Centric Performance
Powered by a high-resolution 8MP CMOS sensor with 3840 × 2160 Ultra HD output, the camera delivers exceptional image clarity and fine-detail reproduction for demanding inspection tasks. Progressive scan technology ensures smooth, distortion-free imaging, while automatic and manual white balance options provide accurate color representation under varying lighting conditions. The combination of standalone HDMI operation and USB connectivity offers a user-friendly workflow that supports real-time observation, image capture, video recording, and efficient data management, helping users achieve higher productivity and inspection accuracy.
Yes, our microscope camera supports direct image and video saving to a USB flash drive via its USB 2.0 interface. This standalone capability means you can operate and record without needing a PC, enhancing flexibility during inspections or research.
We employ the 1/2.8" Sony CMOS sensor to provide sharp 2MP images at 1080P resolution and 60fps. This sensor ensures high sensitivity and excellent dynamic range, delivering clear and consistent visuals critical for precision work in industries requiring a hdmi microscope camera.
We focus on versatile designs like the HDMI USB microscope camera with adjustable exposure and white balance modes. While we provide standard cameras with proven reliability, please contact us to discuss your custom requirements for tailored imaging solutions.
We provide detailed user manuals and technical support to ensure smooth installation and operation. Our team is available to assist with setup and troubleshooting to maintain optimal camera performance across your inspection or research operations.
