Biological Microscope Specification
| Optical system | Infinity corrected optical system |
| Eyepiece | WF10X/22mm high eye point wide field eyepiece; diopter adjustable ±5, tube diameter φ30mm |
| Object lens | Infinity plan objective 4X,10X, 40X(S), 100X(S,Oil) |
| Viewing head | Trinocular head, 30° inclined, Interpupillary distance 50-75mm |
| Converter | Four holes inward |
| Stage | 220*148mm double layer X-axis steel wire transmission mechanical moving platform, travel 76*50mm, accuracy 0.1mm,damping type double slice clamp |
| Condenser | Aplanatic condenser system （with phase cotrast, dark field, polarizer ports interface) |
| Focusing | Coaxial coarse focusing mechanism, micro-adjustment value 0.002mm |
| Illumination | 3W LED light brightness continuously adjustable lighting system |
| Video adapter | 0.5X |
