| Image Sensor |
1/2.8" CMOS |
| Total Pixels |
2MP |
| Zoom |
12x optical zoom,10x digital zoom, total magnification 100x |
| Shooting Area |
A4 and below |
| Focus |
Automatic / Manual |
| Resolution |
1920x1080, 1024x768 |
| Horizontal Resolution |
≥1000TV lines |
| Frame rate |
45fps(optional: 30fps) |
| Lamp |
LED light with three-level dimming |
| White balance |
Automatic |
| Free Software |
Visualizer, supports Windows® 7, 8, 10, 11 |
| IR Remote Control |
Standard |
| Built-in Mic |
Standard |
| Operating Voltage |
12V DC power adapter |
| Input Interface |
1 × HDMI, 1 × VGA, 1 × AUDIO |
| Output Interface |
1 × HDMI, 1 × VGA, 1 × AUDIO, 1 × USB 2.0 Type-B (UVC) |
| Device Dimension |
Folding Dimension: 441*220*90mm
Unfolding Dimension: 415*220*486mm |
| USB Video Stream Format |
Support MJPG |
| Image Format |
Support JPG/BMP/PNG/TIF/PDF |
| Image Storage |
Stored on the computer or USB flash drive via PC software (Visualizer). |
| Buttons Function |
Power, Sourcing, Lamp, Auto Focus, Zoom in&out, Brightness+-, Rotate, Freeze |
| N.W./G.W. |
4.25kg/5.5±0.5kg |
| Anti-Theft |
Mechanism Locker with Keys |
